Metal Parts Toys Castors Sealing Packing Machine Data Line Filling 3 Sides Seal Packaging Machine

Name: Metal Parts Toys Castors Sealing Packing Machine Data Line Filling 3 Sides Seal Packaging Machine
Brand: XingKe
Price: 3 USD

Buy cheap Metal Parts Toys Castors Sealing Packing Machine Data Line Filling 3 Sides Seal Packaging Machine product

Type : Multi-Function Packaging Machine

Production Capacity : 1-60 packs/min

Applicable Industries : Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advert

Weight (KG) : 100

Showroom Location : None

Condition : New

Function : FILLING, Sealing, Automatic packaging

Application : Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware

Packaging Type : Bags, Film, Foil, Three edge-sealing

Packaging Material : Plastic, Paper, Metal, Glass, Wood, CPP

Automatic Grade : Automatic

Driven Type : Electric

Voltage : 220V

Place of Origin : Guangdong, China

Brand Name : XingKe

Dimension(L*W*H) : 1700*750*1550 MM

Warranty : 1 years

Key Selling Points : Easy to Operate

Machinery Test Report : Not Available

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Motor, PLC, Other, Bearing, Solenoid valve, cylinder

Bag type : Back Sealing

Product name : Automatic Vertical Packing Machine

Usage : Filling Packing Machine

Main Function : Weighing Forming Filling Sealing

Packing material : CPP OPP

Feature : Easy Opperation

Bag length : 30-165mm

Advantage : Servo Motor Control

Packing speed : 1-100 Bags/min

Keyword : Packaging Machinery Equipment

Packaging Details : Packed in wooden cases

Port : guanghzou

Supply Ability : 20 Set/Sets per Month

Price : $3,850.00/sets >=1 sets

MOQ : 1set

Delivery Time : 10-15 days

Payment Terms : T/T / west Union/ Money gram / Credit Card

Contact Now

Product Description

Equipment model:	XK-B860P
Counting method:	manual placement
Bag size:	width 40-140 length 200 (conventional 140)
Packing speed:	1-60 bags/min
Sealing shape:	stripe, back sealing/three side sealing (conventional back sealing)
Voltage power:	220V/50HZ P≈0.6KW
Air supply:	0.4-0.8MPA
Bag mouth shape:	figure cutter tooth shape
Dimensions:	length 1700mm/ width 750mm/ height 1550mm
Weight:	about 100KG

Metal Parts Toys Castors Sealing Packing Machine Data Line Filling 3 Sides Seal Packaging Machine

1) Technical characteristics
1.Vibrator bowl automatic arrangement of materials, automatic counting, automatic filling, automatic packing, sealing function,output count.
2.Adopt intelligent temperature control system, stable temperature control, temperature can be adjusted according to needs.
3.The length of packaging bag is adjustable, the total number of packaging is adjustable, the set number of automatic alarm.
4. After packing, the bag is uniform, neat, beautiful and firm. It can also be equipped with coding machine, check weighing, labeling machine, hoist and other expansion equipment.

2) Scope of application and functional features
1.This product is suitable for products with long, irregular product shapes, large length and width ratios, or products that have extremely high surface requirements. such as electroplating, spray painting, baking varnish and other process treatments, electroplating process plastic products, toys, bolts, screwdrivers, Data , etc., using manual material input, belt conveying material to the forming machine, automatic filling and packaging.
2. It is suitable for "OPP/CPP/ lamination film" as sealing material.
